Videosonde Data
R/V Mirai MR06-05 (MISMO) Cruise
1. List of videosondes
launched during MR06-05 cruise (MISMO).
|
Sonde # |
Date |
Time (LST) |
Location |
Remarks |
|
|
lon. |
lat. |
||||
|
1 |
Oct. 26, 2006 |
1513 |
80.73 |
-1.71 |
stratiform
cloud, bright band, small ice particles, large dendrites near the cloud top,
cloud top: 7km |
|
3 |
Nov. 6, 2006 |
1808 |
80.51 |
-0.04 |
stratiform
cloud, weak rain, launched into the center of small weak echo, small ice
particles, no aggregate |
|
4 |
Nov. 12, 2006 |
1806 |
80.46 |
-0.04 |
stratiform
cloud just after convective cloud passing, bright band, small raindrops, many
ice crystals, snowflakes, cloud top: 12km |
|
8 |
Nov. 12, 2006 |
2106 |
80.49 |
-0.04 |
stratiform
cloud, moderate rain, bright band, small raindrops, ice crystals, graupel,
snowflakes, cloud top: 8km |
|
7 |
Nov. 20, 2006 |
0302 |
80.50 |
-0.07 |
stratiform
cloud after dissipated convective cloud, small raindrops, many ice crystals,
cloud top: 8km |
|
12 |
Nov. 20, 2006 |
0515 |
80.48 |
-0.01 |
stratiform
cloud in the larger cloud system, many ice crystals above the freezing level,
cloud top: 15km |
|
15 |
Nov. 21, 2006 |
0251 |
80.55 |
-0.02 |
dissipating
stratiform cloud, weak rain, small ice crystals, no snowflake, cloud top: 8km |
2. Precipitation Particle Images
(Sample Videosonde #12 launched on November 20, 2006)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3. Precipitation Particle Distribution
Diagram (Sample)
4. Text Data (Sample)
5. Data Archive
The original data will be archived at and available from
